TP-Link RE305 AC1200 Wall Plugged Wi-Fi Range Extender

Stable Dual Band Wi-Fi Extension to Bring Dead Zones to Life

Overview:

• Brings Wi-Fi dead zone to life with strong Wi-Fi expansion at combined speed of up to 1.2Gbps.


• Operates over both the 2.4GHz band(300Mbps) and 5GHz band(867Mbps) for more stable wireless experience.


• Intelligent signal light helps to fi¬nd the best location for optimal Wi-Fi coverage by showing the signal strength.


• Works with any Wi-Fi router or wireless access point.

Easily Expand Your Wi-Fi Coverage
Tired of Wi-Fi dead zones in your home? The RE305 Range Extender connects to yoyur Wi-Fi router wirelessly, strengthening and expanding its signal into areas it can't reach on its own, while reducing signal interference to ensure reliable Wi-Fi coverage throughout your home or office.

High-Speed Dual Band Wi-Fi for Better Connections
The RE305 lets you keep more devices connected at the same time with its 2.4GHz 300Mbps and 5GHz 867Mbps dual bands. Use the 2.4GHz band to send email and browse the web, and the 5GHz band for gaming and HD streaming.

Perfect Location at a Glimpse
An Intelligent Signal light helps you quickly find the best location to install the RE305.

Built-in Access Point Mode
RE305 is more than a wireless range extender. Simply plug the Ethernet cable into its Ethernet port to easily turn your wired internet connection into a dual band wireless access point.

Easy Management and Remote Control
The RE305 works with all Wi-Fi routers. You can use TP-Link's free Tether app to set up the range extender from any Android or iOS device in minutes. This feature-rich phone app allows you to enjoy not only hassle-free installation, but also access to advanced network management, all at your fingertips.

TP-Link OneMesh™
OneMesh™ is a simple way to form a Mesh network with a single Wi-Fi name for seamless whole-home coverage. Just connect a OneMesh™ range
extender to a OneMesh™ router. No more searching around for a stable connection.

WIRELESS

Working Modes
Range Extender/Access Point

HARDWARE FEATURES

Standards and Protocols
IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11a, IEEE 802.11b

Plug Type
EU, UK, US

Interface
1 * 10/100M Ethernet Port (RJ45)

Ports
1 x 10/100Mbps Ethernet Port (RJ45)

Button
WPS Button, Reset Button

Input Power
100-240V~50/60Hz

Power Consumption
7.3W?max power consumption?

Dimensions ( W x D x H )
3.1*3.0*3.0 in. (80*78*77mm)

Antenna
2* external

WIRELESS FEATURES

Wireless Standards
IEEE 802.11a/n/ac 5GHz, IEEE 802.11b/g/n 2.4GHz

Frequency
2.4GHz & 5GHz(11ac)

Signal Rate
5GHz:Up to 867Mbps
2.4GHz:Up to 300Mpbs

Reception Sensitivity
5GHz
11a 6Mbps:-91dBm@10% PER
11a 54Mbps: -74dBm@10% PER
11ac HT20 mcs8: -68dBm@10% PER
11ac HT40 mcs9: -63dBm@10% PER
11ac HT80 mcs9: -59dBm@10% PER
2.4GHz
11g 54M: -79dBm@10% PER
11n HT20 mcs7: -77dBm@10% PER
11n HT40 mcs7: -74dBm@10% PER

Wireless Modes
Range Extender/Access Point
Wireless Statistic
Concurrent Mode boost both 2.4G/5G Wi-Fi band

Wireless Functions
Wireless Statistic
Concurrent Mode boost both 2.4G/5G Wi-Fi band
Access Control
LED Control
Domain Login Function

Wireless Security
64/128-bit WEP
WPA-PSK / WPA2-PSK

Transmission Power
<17dBm(2.4GHz)
<17dBm(5GHz)

OTHERS

Certification
CE, FCC, RoHS

Package Contents
AC1200 Wi-Fi Range Extender RE305
Quick Installation Guide

Box Dimensions (W X D X H)
6.15*4*3.7in. (156.5*101.5*95mm)

System Requirements
Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.

Environment
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
