M7650 600 Mbps LTE-Advanced Mobile Wi-Fi

• LTE-Advanced cat11 supported with up to 600 Mbps download and 50 Mbps upload speeds


• Supports up to 32 devices simultaneously


• Selectable 300 Mbps at 2.4GHz or 867 Mbps at 5GHz dual band Wi-Fi


• All useful information at a glance with screen display


• 3000 mAh battery for up to 15 hours of working


• Equipped with a micro SD card slot for up to 32GB of optional storage


• Easy management with the tpMiFi App

Fastest Mobile Connection up to 600 Mbps
The M7650 supporting the 4G LTE network LTE-A Cat.11, which is used Carrier Aggregation. This advanced technology merges the fragmented LTE band into a "virtual" wider band to increase the data rate, with the 256-QAM, to provide fast 4G speeds of up to 600 Mbps.

Do More with a Fast Connection
With the fastest 4G speed of up to 600 Mbps, you can enjoy HD movies without interruption, downloading files in seconds, and smooth online gaming. Truly fastest, smoothest, most efficient data transmission.

Your Perfect Daily Wi-Fi Partner
The M7650 provides selectable dual band Wi-Fi, 867 Mbps at 5GHz or 300 Mbps at 2.4GHz. With this convenient companion, you can share your Wi-Fi with your friends everywhere.

Advanced Screen & Menu for Easy Using
The intuitive screen display of M7650 makes it easy to stay within your data budget and avoids going over the monthly data cap. The screen also displays other much more information of battery life, signal strength, Wi-Fi status, connected users and more.

Internet Access for up to 32 Devices Simultaneously
The M7650 can easily share a 4G/3G connection with up to 32 wireless devices like tablets, laptops, and mobile phones at the same time. It can also provide internet access for desktop computers via the integrated USB port.

Power to Keep Working All-day-long
M7650 is equipped with a powerful 3000mAh battery. On its own, it can work effortlessly up to 15 hours at full capacity and stand by for over 900 hours. M7650 can be recharged via a micro USB cable connected to a laptop, portable charger or adapter for endless hours of 4G sharing.

Spread Your Wings with an Elegant Wi-Fi Companion
The smooth curves and elegant, compact design make the lightweight M7650 perfect for personal travel, business trips, outdoor activities, and everywhere else life takes you.

Wireless Media Sharing from Micro SD Card
It's now easier than ever to share photos, music, videos and more in your mobile network from a micro SD Storage - supports optional storage of up to 32G.

Easy Management with tpMiFi App
With the tpMiFi App, you can easily access and manage the M7650 from your connected iOS/Android devices. The tpMiFi app allows you to establish data limits, control which devices can access your Wi-Fi, send messages, and share media files to/from a removable Micro SD card.

HARDWARE FEATURES

Interface
1 micro USB port for power supply
1 Micro SIM card slot
1 Micro SD card slot

Button
Power On/Off Menu

Power Supply
3000mAh Rechargeable Battery

Network Type
FDD-LTE: B1/B3/B7/B8/B20(2100/1800/2600/900/800MHz)
TDD-LTE: B38/B40/B41 (2600/2300/2500MHz)
DC-HSPA+/HSPA/UMTS: B1/B8(2100/900MHz)
EDGE/GPRS/GSM: 850/900/1800/1900MHz

Data Rates
DL: 600Mbps, UL: 50Mbps

Dimensions ( W x D x H )
112.5*66.5*16mm

Antenna
Internal Antenna

Micro SD Card Reader
Up to 32GB

Screen Display
1.44 inch TFT

WIRELESS FEATURES

Wireless Standards
IEEE 802.11a/b/g/n/ac 300Mbps at 2.4GHz or 867Mbps at 5GHz

Frequency
2.4GHz&5GHz

Transmit Power
2.4G <20dbm, 5G <23dbm

Wireless Security
Support WPA-PSK/WPA2-PSK, Wireless MAC Filtering

DHCP
DHCP server, DHCP Client List

OTHERS

RNDIS Support
Yes
System Requirement: Windows XP/7/8/10

Certification
CE, RoHS

Package Contents
600Mbps LTE-Advanced Mobile Wi-Fi M7650
Micro USB Cable
Nano to Micro SIM Card Adapter
3000mAh Battery
Quick Installation Guide

System Requirements
Windows 10/8/7/vista/XP, Mac OS, Android, iOS, Windows Phone
