Product Highlight

==========================================================================================

Usable Capacities

256GB / 512GB

NAND Components

3D NAND

Interface

PCIe Gen 3x4 NVMe 1.3

Form Factor

M.2 2280

Package Dimensions (L×W×H)

123 x 85 x 4.3 mm

Product Dimensions (L×W×H)

22 x 80 x 2 mm

Weight

6.6g

Max Sequential Read*

256GB/512GB: Up to 1700MB/s

Max Sequential Write*

256GB: up to 1100MB/s

512GB: up to 1500MB/s

TBW

256GB: 150 ;512GB: 350

PCIe Link Power Management

APST, ASPM, L1.2

Operating Temperature

0°C to 70°C

Storage Temperature

-40°C to 85°C

Certifications

BSMI, CE, FCC, KCC, VCCI, REACH, RoHS

MTBF

2 Million Hours

Error Correction Code

Less than 1 sector per ten quadrillion bits read

Product Health Monitoring

Self-Monitoring, Analysis and Reporting Technology (S.M.A.R.T)

Full End-to-End Data path protection

Supported

Performance Optimization

TRIM (requires OS support)
