Dimensions

Height: 162.9 mm

Width: 76.5 mm

Thickness: 8.5 mm (Arctic Dawn/Black Eclipse) 8.9 mm (Midnight Ocean)

Weight: 213g (Arctic Dawn/Black Eclipse) 210g (Midnight Ocean)

Display

Parameters

Size: 17.32 cm (6.82 inches, measured diagonally from corner to corner)

Resolution: 3168*1440 (QHD+), 510 ppi

Aspect Ratio: 19.8:9

HBM / Peak Brightness: 1600 / 4500 nits

Refresh Rate: 1-120 Hz dynamic

Type: 120Hz ProXDR Display with LTPO 4.1

Support 100% Display P3, 10-bit Color Depth

Cover Glass: Ceramic Guard

Features

Nature tone display

Eye comfort

Bedtime mode

Image sharpener

Video color enhancer

Screen color mode

Color vision enhancement

Auto brightness

Manual brightness

Screen Color Temperature

Bright HDR video mode

Night mode

Multi-brightness color calibration

Performance

Operating System: OxygenOS 15.0 based on Android™ 15

Platform: Snapdragon® 8 Elite Mobile Platform

CPU: Qualcomm® Oryon™ CPU @4.32GHz

GPU: Adreno™ 830

RAM: 12GB/16GB LPDDR5X

Storage: 256GB/512GB UFS 4.0

Battery: 6,000 mAh (Dual-cell 3,000 mAh, non-removable)

Vibration: Haptic motor

Available configurations: 12GB+256GB / 16GB+512GB

Charge

100W SUPERVOOC™

50W AIRVOOC

Camera

Main Camera

Sensor: Sony's LYT-808

Sensor Size: 1/1.4"

Megapixels: 50

Pixel Size: 1.12 µm

Lens Quantity: 7P

ALC lens coating

Optical Image Stabilization: Yes

Electronic Image Stabilization: Yes

Focal Length: 23 mm equivalent

Aperture: ƒ/1.6

Field of View: 85°

Autofocus: Yes

Telephoto Camera

Sensor: Sony LYT-600 with 3X optical zoom

Sensor Size: 1/1.95"

Megapixels: 50

Pixel Size: 0.8 µm

Lens Quantity: 1G3P

ALC lens coating

Optical Image Stabilization: Yes

Electronic Image Stabilization: Yes

Focal Length: 73 mm equivalent

Aperture: ƒ/2.6

Field of View: 32.8°

Autofocus: Yes

Ultra Res (digital) Zoom: Up to 120X

Ultra-wide Camera

Sensor: S5KJN5

Sensor Size: 1/2.75"

Megapixels: 50

Pixel Size: 0.64 µm

Lens Quantity: 6P

Electronic Image Stabilization: Yes

Focal Length: 15 mm equivalent

Aperture: ƒ/2.0

Field of View: 120°

Autofocus: Yes

Flash

LED

Autofocus

Multi Autofocus(All pixel omni-directional PDAF+CAF+LDAF)

Video

The rear supports 8K at 30 fps, 4K at 60 fps/30fps, 1080p at 60 fps/30fps and 720p at 30 fps

Steady video: 4K at 60 fps/30fps and 1080p at 60fps/30fps

Video zoom shooting support: 4K at 60 fps/30 fps, 1080p at 60fps/30fps, 720p at 30fps

Dolby Vision: 4K at 60 fps/30 fps, 1080p at 60 fps/30 fps

Movie mode:4K at 30 fps

Time lapse: 4K at 30 fps and 1080p at 30 fps

Multi-scene video recording supports 1080p at 30 fps

Slo-mo video: 1080p at 240 fps, 720p at 480 fps/240 fps

Features

Photo, Video, Portrait, Nightscape, Master, High Pixel, Panorama, Movie, Slow Motion, Timelapse, Long Exposure, Multi-Scene Video, Document, Axis Shift, XPAN

Front Camera

Sensor: Sony IMX615

Megapixels: 32

Sensor Size: 1/2.74"

Lens Quantity: 5P

Pixel Size: 0.8 µm

Electronic Image Stabilization: Yes

Focal Length: 21 mm equivalent

Autofocus: Fixed Focus

Aperture: ƒ/2.4

Field of View: 90°

Video

Video: 4K at 60 fps/30fps, 1080p at 60 fps/30 fps, 720p at 30 fps

Steady video 1080p at 30 fps, 720p at 30 fps

Dolby Vision: 4K at 60 fps/30 fps, 1080p at 60 fps/30 fps

Features

Photo, video, portrait, night scene, panorama, time-lapse photography, multi-scene video recording

Connectivity

LTE/LTE-A

4×4 MIMO, Supports up to DL Cat 20/UL Cat 18 (2000Mbps /200Mbps), depending on carrier support

Band

2G GSM: 850/900/1800/1900MHz

3G WCDMA:Bands 1/2/4/5/6/8/19

4G LTE FDD: Bands 1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/28/30/32/66/71

4G LTE TDD: Bands 38/39/40/41/48

5G SA: n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/n30/n38/n40/n41/n48/n66/n71/n75/n77/n78

Wi-Fi

Wi-Fi 7, Wi-Fi 6, Wi-Fi 5, WLAN Display, WLAN tethering, WLAN overlay, 160 MHz Wi-Fi channels over 5 GHz, 320 MHz Wi-Fi channels over 6 GHz, 2X2 MIMO

Bluetooth

Bluetooth® 5.4

SBC, AAC, aptx, aptx-HD, LDAC, LHDC5.0

NFC

NFC enabled

Positioning

GPS(L1+L5), GLONASS(G1), BDS(B1I+B1C+B2a), Galileo(E1+E5a), QZSS(L1+L5)

Sensors

Proximity sensor

Ambient light sensor

Color temperature sensor

Compass

Acceleration sensor

Gyroscopes

Ultrasonic fingerprint

Hall sensor

Laser focus sensor

Spectral sensors

Infrared remote control

Barometer

Ports

USB 3.2 Gen 1

Type-C

Support standard Type-C earphones

Dual nano-SIM slot

Buttons

Gestures and on-screen navigation support

Alert Slider

Audio

OReality Audio

Noise cancellation support

Multimedia

HDR Supported

Dolby Vision®, HDR 10+, HDR Vivid

Audio Supported Formats

MP3, AAC, AMR, APE, OGG, FLAC, WAV

Video Supported Formats

MP4, 3GP, MKV, MOV, AVI, FLV, HEVC, AVC, VP9, VP8, AV1

Image Supported Formats

JPEG, BMP, PNG, DNG, HEIF, AVIF, WEBP, GIF, WBMP, ICO

In The Box

OnePlus 13

Type-A to C Cable

Quick Start Guide

SIM Tray Ejector

Safety Guide
