- Dolby Atmos® and MultiBeam™ Surround Sound.
- Built-In Wi-Fi with AirPlay, Alexa Multi-Room Music and Chromecast built-in™
Dolby Atmos® and MultiBeam™ Surround Sound
Immerse yourself in theater-quality 3D surround sound. Hear extraordinary sound effects from everywhere in the room, without the need for extra surround speakers.
Built-In Wi-Fi with AirPlay, Alexa Multi-Room Music and Chromecast built-in™
Get ready to explore. Access over 300 online music streaming services through AirPlay, Alexa MRM and Chromecast built-in™. Enjoy all of your favorite audio content, Internet radio, and podcasts in high definition. The Wi-Fi connection also allows automatic software updates, so you can always enjoy the latest features.
590W output power
With 590 watts of total system output power, the JBL Bar 500 transforms your movies, music and games into immersive sound experiences.
Easy Sound Calibration
Every room is different. Our audio calibration feature ensures that the JBL Bar 500 delivers the best 3D surround effects for any interior and room layout.
Works with voice assistant-enabled speakers
Simply link the JBL Bar 500 with your voice assistant-enabled device and you can instantly ask Alexa, Google Assistant, or Siri to stream all your favorite music to the soundbar.
10" Wireless subwoofer
Thrilling, precise bass from a mighty 10" wireless subwoofer brings the action to your movies and the emotion to your music.
PureVoice Dialogue Enhancement Technology
PureVoice technology uses our unique algorithm to optimize voice clarity to ensure you never miss a word of dialogue, even when the surround effects are at their peak.
HDMI eARC with 4K Dolby Vision Passthrough
Enjoy uncompressed Dolby Atmos surround sound through a single HDMI cable thanks to the HDMI eARC connection. The HDMI input connection also offers 4K video quality from a compatible video player or gaming console.
JBL One App
Customize EQ and control all of your compatible speakers with a single convenient app. The JBL One app helps you easily set up the soundbar, personalize settings, and browse the integrated music services to find your new favorite song.
General Specifications
Power supply: 100 - 240V AC, ~ 50/60Hz
Networked standby power: < 2.0 W
Operating temperature: 0°C - 45 °C
Audio Specifications
Total speaker power output (Max @THD 1%): 590W
Soundbar output power (Max @THD 1%): 290W
Subwoofer output power (Max. @THD 1%): 300 W
Soundbar transducer: 4x (46x90)mm racetrack drivers, 3x 0.75" (20mm) tweeters
Subwoofer transducer: 10” (260mm)
Frequency response: 35Hz - 20kHz (-6dB)
Audio inputs: 1 Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)
Dimensions
Soundbar dimensions (W x H x D): 1017 x 56 x 103.5 mm / 40’’ x 2.2’’ x 4’’
Subwoofer dimensions (W x H x D): 305 x 440.4 x 305 mm / 12" x 17.3" x 12"
Soundbar weight: 2.8kg/ 6.2 lbs
Subwoofer weight: 10 kg / 22 lbs
Packaging dimensions (W x H x D): 1105 x 370 x 475 mm/ 43.5" x 14.6" x 18.7"
Packaging Weight: 16.2 kg / 35.6 lbs
Control and Connection Specifications
USB port: Type A
USB rating: 5V DC, 0.5A
Supporting file format: MP3
MP3 codec: MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
MP3 sampling rate: 16 - 48 kHz
MP3 bitrate: 80 - 320 kpbs
Bluetooth versionL: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400 MHz – 2483.5 MHz
Bluetooth transmitter power: <15 dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 - 2472 MHz (2.4 GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power: < 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range: 5.15 - 5.35GHz, 5.470-5.725GHz, 5.725 - 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz & 5.47-5.725GHz <20dBm, 5.725-5.825GHz <14dBm (EIRP)
2.4G wireless transmitter frequency range: 2406 - 2474MH
2.4G wireless transmitter power: <10dBm (EIRP)
What's in the box?
1 x Main Soundbar
1 x Wireless subwoofer
Remote control with 2 x batteries
Power cords (up to 8pcs depending on region SKUs)
1 x HDMI cable
2 x L-shape wall-mount bracket with screws
Quick start guide
Safety Instruction and Warranty Card
Wall mount template
| Brand | JBL |
|---|---|
| Category | Audio > Home Audio |
| Product Condition | New |
| Warranty Period | 1 Year |
