Printer

Maximum Printing
Resolution : 9600 (horizontal)*¹ x 2400 (vertical) dpi

Print Head / Ink
: Type: : Individual Ink Tank

 : Number of Nozzles: : Total 5,120 nozzles

 : Ink Droplet Size: : 1pl

 : Ink Tank: : PGI-750 (Pigment Black), CLI-751
(Cyan / Magenta / Yellow / Black)

[Optional: PGI-755XXL (Pigment Black), PGI-750XL (Pigment Black),

CLI-751XL (Cyan / Magenta / Yellow / Black)]

Print Speed

Based on ISO / IEC 24734.

 : Document: Col : ESAT / Simplex : . 10.4 ipm

 : Document: B/W : ESAT / Simplex : . 14.5 ipm

 : Photo (11 x 14" image) : PP-201 : . 120
sec

 : Photo (4 x 6") : PP-201 / Borderless : .
36 sec

Printable Width
: Up to 322.2 mm (12.7 inch), Borderless: Up to 329 mm (13 inch)

Printable Area :
Borderless Printing*³ : Top / Bottom /
Left / Right margin: each 0 mm (Supported Paper Size: A3+, A3, A4, LTR, LDR, 4
x 6", 5 x 7", 8 x 10", 10 x 12")

 : Bordered Printing : Top margin: 3 mm, Bottom
margin: 5 mm,

Left / Right margin: each 3.4 mm (LTR / LGL: Left: 6.4 mm, Right: 6.3 mm)

Recommended
Printing Area : Top margin: 40.7 mm / Bottom margin: 37.4 mm

Paper Size : A3+,
A3, A4, A5, B4, B5, LTR, LGL, LDR, 4 x 6", 5 x 7", 8 x 10", 10 x
12", Envelopes (DL, COM10), Custum size (width 55 - 329 mm, length 91 -
676 mm)

Paper Handling
(Rear Tray)

(Maximum Number) : Plain Paper : A3, A4, A5, B4, B5, LTR, LGL, LDR = 150

 : High Resolution Paper (HR-101N) : A3+ = 20,
A3 = 50, A4 = 80

 : Photo Paper Pro Platinum (PT-101) : A3+ = 1,
A3, A4 = 10, 4 x 6" = 20

 : Photo Paper Plus Glossy II (PP-201) : A3+ =
1, A3, A4 = 10, 4 x 6" = 20

 : Photo Paper Pro Luster (LU-101) : A3+ = 1,
A3, A4 = 10

 : Photo Paper Plus Semi-Gloss (SG-201) : A3+ =
1, A3, A4, 8 x 10" = 10, 4 x 6" = 20

 : Glossy Photo Paper "Everyday Use"
(GP-601) : A4 = 10, 4 x 6" = 20

 : Matte Photo Paper (MP-101) : A3, A4 = 10, 4
x 6" = 20

 : Envelope : European DL / US Com. #10 = 10

Paper Weight : Front
Tray : Plain Paper: 64 - 105 g/m², Canon specialty paper: max paper weight: . 300 g/m² (Photo Paper Pro Platinum PT-101)

Ink End Sensor :
Optical sensor + Dot count

Print Head
Alignment : Auto / Manual

Network :

Protocol : TCP /
IP

 : Data Rate : 10 M / 100 Mbps (auto
switchable)

Wireless : Network
Type : IEEE 802.11b/g/n

 : Frequency Band : 2.4 GHz

 : Channel : 1 - 13

 : Range : indoor 50 m

 : Security : WEP 64 / 128-bit, WPA-PSK (TKIP /
AES), WPA2-PSK (TKIP / AES)

System
Requirements

 : Windows 8 / Windows 7 / Windows XP / Windows
Vista

Macintosh:
:  : Mac OS X 10.6.8 and later

General
Specifications :

Interface : Wireless
LAN IEEE 802.11b/g/n, 100 Base-TX / 10 Base-T, USB 2.0 Hi-Speed

Apple AirPrint :
Available

PIXMA PRINT
Inkjet/SELPHY : Available

Acoustic Noise
(PC Print) : Photo (4 x 6")*⁵ :  44.0 dB(A)

Power : AC 100 -
240 V, 50/60 Hz

Power
Consumption : Standby

Wireless LAN connection to PC : . 2.0 W

 : OFF: : . 0.3 W

 : Printing*⁶

Wireless LAN connection to PC : . 24 W

Duty Cycle :
: up to 12,000 pages/month

Dimension (W x D
x H) :   : . 584 x 310 x 159 mm

Weight :
: 8.1 kg
